The compact DISOMAT® Tersus weighing terminal is ideal for use in a wide range of weighing applications, regardless of whether you’re focusing on operating. DISOMAT® Tersus to control a crane DISOMAT® Tersus panel-mounting unit in field housing DISOMAT® Tersus Crane Scale, see Manual BV-HAA. A Schenck model DISOMAT Tersus (VTG ) digital indicator as shown in between weighing ranges may be automatic or manual.

Author:Shagar Arakasa
Language:English (Spanish)
Published (Last):1 September 2010
PDF File Size:3.94 Mb
ePub File Size:4.58 Mb
Price:Free* [*Free Regsitration Required]

Disocont Vse 20100 Manual Pdf

A fieldbox with a high degree of protection is available. Installation Prerequisites n n n The housing is protected to IP The firmware and all individual set parameters are backed up and restored in next to no time. Local Box VVG 4. Other benefits at a glance: No special jumper position must be observed.

% System accuracy for weighing tasks better than 0.05%% Manual and/or automatic zero setting% Full feed/dribble feed control for accurate batching% High electromagnetic compatibility% Galvanically isolated outputs% Totalizing counter pulses% Fail-safe data memory (EEPROM)% Integrated diagnostics and self-testing functions (SPC)% Default. Operating Manual For Schenck Process Intecont Plus DISOCONT/INTECONT Tersus Language Files.zip File with text to be loaded into controller (loadable language) to provide local language dialogs on operator panel and presentation in EasyServe 2018-12-11 Schenck Process Group - Free Downloads. Jun 16, 2020 The present manual is valid from firmware version Vxxyy For further reading For further information, please refer to the documents below. For ordering numbers, see Spare Parts list: Safety Instructions Use As Originally Intended The measuring system and nanual connected mechanical components are exclusively designed for weighing and controlling. DISOMAT® Tersus weighing terminal% A weighing terminal with all the equipment% Clear operator guidance on a graphics- compatible back-lit LCD display% Built-in Ethernet port.

In the safe area, the sealing ring may be exchanged; certified screwed connections must be replaced in set. In operation with two measuring channels: Sources of Danger No danger originates from the measuring system itself, if it is properly installed and commissioned. Measure voltage using a suitable instrument e. Fitting D is provided for fieldbus connectors. The ICP module interface parameters are fixed: Housing The mechanical installation depends on the selected type of housing.

A list of fieldbus accessories is given on page Ensure that both jumpers are in the same position. For connection of secondary displays, see wiring diagram page This problem can be avoided with the use of a separate active terminal resistor, e. We use cookies our own and those of third parties to make it easier for you to use our websites. If the fuse responds, you can replace it by a new one featuring the same rated data. Check to see that connected control systems, if any, are in fail-safe state.


If bus boards are equipped with jumpers for configuration, set these before mounting accessiblity.

Open device and dongle housing from the side using a screw driver. In the case of load cell supply, this value depends on the total impedance and thus tetsus the number of load cells.

The use of a bus termination as shown below offers a reliable remedy. Subject to change without prior notice.

Explosion-proof Protective Circuitries Fig. Interfaces Connectors Data Organization Data stored in the legal-for-trade memory cannot neither be manipulated nor loaded down with the use of standard tools.


Disocont vcu 20100 manual pdf

Installing Storage Module To insert module in position XE1, push it into the receptor with arrow down inclined edge to the lower left. The housing is protected from water jets to IP This means that the operation from the PC keyboard disomst exactly the same as on the device direct. Manipulation of dongle leads to the loss of calibration data.

For maunal, see manual BV-H Observe housing protection standards. For further mnaual For further disonat, please refer to the documents below. Explosion-proof Protective Circuitries Maximal load cell distance: Remove clamping nut and press in plug flush with the screwed connection outer edge. The optional memory expansion provided by the USB stick makes the device ideal for even more extensive applications.

The table below lists the available variants: If other makes are used, the warranty will be void. Separate flat cable connectors of connector board from measuring circuit board. Safety Hints 1 2 Always mount explosion-proof protective circuitries in the safe area. Explosion-proof Protective Circuitries Maximum load cell distance: Use screened cable and contact screen using clamp.


RS and RS can be used as alternative only 1 physical interface. Under unfavourable conditions, communication errors can occur in spite of proper connection of the ICP modules.

Do not use any external circuitry to invert this logic; this would affect wire-break safety and disable further processing of signals in DISOMAT. For 12Mbaud, the following physical restriction additionally applies: In case of verification, bond stamp onto housing seam.

Any use other than originally intended is considered inappropriate. Real time clock RTCmin. The passive bus connection can then be omitted. Sustainable in all regards: Fieldbus Interfaces Connectors 5.
